Beautiful borehole logs, built from the field up.
BHLCS helps teams build accurate soil and cored borehole logs in less time. Its high-performance PDF engine turns detailed field records into precise, easy-to-read outputs.
Work offline on a desktop, tablet or phone, then bring your borehole data together through cloud sync. Native apps are built for Windows, macOS, Linux and mobile operating systems.
One place for the whole borehole story.
BHLCS is optimised for AS 1726:2017 geotechnical site investigations and Department of Transport and Main Roads borehole logging standards. The previews below use illustrative sample data.
Log wherever work happens
Move between the site, the office and the devices your team uses.
-
BHLCS · DEMOOffline
Borehole workspace
Riverbend Site
Saved on this deviceBH-04✓ Lithology interval09:14✓ SPT result09:32✓ Core photo09:473 changes ready for cloud sync
01 / FEATUREOffline first, centrally managed
Keep logging when a site has no connection. Borehole records stay available on the device and can sync to a central project workspace when connectivity returns.
-
BHLCS · DEMO
Native applications
One project, every screen
DesktopTabletMobile02 / FEATUREDesktop, tablet and mobile
Work on Windows, macOS, Linux, tablets or mobile devices. Native applications let the same investigation continue across the equipment your team uses.
-
BHLCS · DEMO3 records
BH-04 · In-situ tests
Field test register
TestDepthResultSPT3.0 mN = 18DCP4.5 m12 mmCPT6.0 m8.2 MPa03 / FEATURERecord in-situ tests
Keep SPT, CPT, DCP and other field test observations close to the relevant hole and depth. Bring test data into the same record as the ground description.
Describe the ground
Build a detailed record of soil, rock and site context.
-
BHLCS · DEMOLogged
BH-08 · Rock core
Core run 12.0–15.0 m
12 m
13 m
14 mStrength · High
Weathering · Slight
Discontinuities · 3 sets
Defect spacing · 180 mm
04 / FEATUREAdvanced core logging
Describe rock strength, weathering, discontinuities and defect spacing in a structured core record. See the observations in depth order as the log takes shape.
-
BHLCS · DEMO3 holes
Section A–A′
Ground profile
● Fill● Sand● Rock05 / FEATURECreate cross sections
Connect boreholes across the site to communicate changing ground conditions. Turn individual logs into a clear visual section for the project team.
-
BHLCS · DEMO010408Riverbend Site3 holes shown
Site map · Borehole locations
06 / FEATUREMap the investigation
See hole positions and site information together. Mapping tools help teams understand where each record belongs within the wider investigation.
Deliver with confidence
Turn captured data into consistent project outputs.
-
BHLCS · DEMOPDF ready
Visual log preview
BH-08 · Sheet 1 of 2
BOREHOLE LOGBH-080
2
4
6Sandy gravelly FILLStiff silty CLAYWeathered SANDSTONE07 / FEATUREProduce precise visual logs
Create clear soil and cored borehole logs with the high-performance PDF engine. Review a visual preview before sharing the finished document.
-
BHLCS · DEMO8 holes
Site investigation
Riverbend Site
▤ BH-04 · 6.0 mOpen↳ Geology 6 intervals
↳ Samples & tests 3 records
↳ Comments 2 notes
↳ Visual log Preview
08 / FEATUREConnect site investigations
Keep borehole records connected to the rest of the geotechnical site investigation. Organise holes, samples, tests and comments within the project workflow.
-
BHLCS · DEMOReady
Data exchange
AGS export
AGSRiverbend_Site.agsInvestigation data · 8 holes8Holes42Intervals19Tests09 / FEATUREExport AGS data
Prepare structured AGS exports for exchanging investigation data. Give downstream teams a format they can use alongside the finished logs.
Make every borehole record count.
Talk with our team about your logging standards, field workflow and reporting needs.
